Core Count : 4P
Category : Female
Applications : Power, Signal
Panel-mounted wire bonding type:
Anti-misinsertion coding design: The D coding is its core identifier, which can precisely match the specific pin definitions, effectively avoiding misinsertion with M12 connectors of A, B, X, etc. from other encodings, ensuring the connection accuracy of Ethernet, Profinet, and EtherCAT and other protocol devices. This is the key design that enables it to adapt to specific industrial communication scenarios. Panel mounting and wire bonding connection: Panel mounting can be adapted to various installation methods of PCB boards, such as straight mounting and bent mounting. Some models also support SMT surface mounting technology, suitable for dense installation scenarios like double-sided assembled PCBs; Wire bonding connection fixes the wires and contacts through welding, ensuring a firm connection and reducing contact problems due to vibration in industrial environments, suitable for on-site wiring requirements. Core application scenarios: This connector is a core connection component in the field of industrial automation. For example, signal transmission between sensors and controllers in automated production lines, Ethernet communication connections at robot joints, and data interaction interfaces in automotive manufacturing equipment.
|
Product model
|
Core
|
Rated current
|
Rated voltage
|
Wire gauge / Dimension
|
||
|
A/C
|
D/C
|
AWG
|
mm²
|
|||
| MC12DF-04R2LSLLS301 |
4
|
4A
|
250V
|
250V
|
22
|
0.34
|
| Core | 2A | 3A | 4A | 5A |
| male end |
|
|
|
|
| 6A | 8A | 12A | 17A | |
|
|
|
|
|
|
| 4B | 5B | 3C | 4C | |
|
|
|
|
|
|
| 5C | 6C | 4D | ||
|
|
|
|
||
| Core | 2A | 3A | 4A | 5A |
| female connector |
|
|
|
|
| 6A | 8A | 12A | 17A | |
|
|
|
|
|
|
| 4B | 5B | 3C | 4C | |
|
|
|
|
|
|
| 5C | 6C | 4D | ||
|
|
|
|
|
The connector must not be plugged or unplugged under load. Failure to follow the instructions and improper use can result in personal injury.
The development of the connector is aimed at being applied in factory engineering, control and electrical equipment construction. Users are responsible for checking whether the connector can also be used in other applications.
Connectors used in circuits with dangerous voltages that cause electric shock must be installed and used only by personnel who have received training in electrical engineering, or under their supervision, while taking into account the applicable regulations and standards.
Users must take appropriate security measures to ensure that the connectors do not accidentally disconnect.
When installing, apply moderate force and use the special tool to tighten the nuts. Avoid excessive force to prevent the shell from deforming or the pins from bending. Ensure that the plug and socket are fully engaged. Do not power on the device when not locked in place to prevent arc discharge due to poor contact.
The plug connectors with an enclosure protection rating of IP67 and IP68 are not suitable for use in water. When used outdoors, the plug connectors must be protected against corrosion separately. For further information on IP protection ratings, please refer to "Technical Information".
